Q-Mark Probe Styli: Orders Placed by Noon PT Ship Out Same-Day* | Ultra-Fast Service | Always Guaranteed | Proudly USA Made

TM4-4052-C-BL

Name: TM4-4052-C-BL
Brand: Q-Mark Manufacturing Inc.
Price: 195.0 USD
Availability: InStock

$195.00

{% if Machines.userdata.machines[0].parts %} {% assign compatible = false %} {% for machine in Machines.userdata.machines %} {% if machine.parts contains title %} {% assign compatible = true %}

Compatible with

{% endif %} {% endfor %} {% unless compatible %}

This product is not compatible with any of your saved machines.

{% endunless %} {% else %} {% endif %}

Quantity

M4 stylus for Blum probe. 4.0 mm diameter ruby ball, 2.5 mm diameter carbide stem, 4.5 mm diameter ceramic body, and 7.0 mm diameter stainless steel base. Stylus length to ball center is 50.0 mm. Compare to Blum P03.8000-020.050.04.

Dimensions

ball diameter: 4.0

base diameter: 7.0

body diameter: 4.5

length 1: 52.0

length 2: 13.0

stem diameter: 2.5

Materials

ball material: Ruby

base material: Stainless Steel

body material: ceramic

stem material: Carbide
