TM4-3056.5-EC

Name: TM4-3056.5-EC
Brand: Q-Mark Manufacturing Inc.
Price: 146.0 USD
Availability: InStock

$146.00

{% if Machines.userdata.machines[0].parts %} {% assign compatible = false %} {% for machine in Machines.userdata.machines %} {% if machine.parts contains title %} {% assign compatible = true %}

Compatible with

{% endif %} {% endfor %} {% unless compatible %}

This product is not compatible with any of your saved machines.

{% endunless %} {% else %} {% endif %}

Quantity

M4 stylus with 3.0 mm diameter carbide ball and stainless steel base and stem. Stylus is electrically conductive. Stylus length to ball center is 50.0 mm. Weight is 3.82 grams. Compare to Renishaw A-5000-9697.

Dimensions

ball diameter: 3.0

base diameter: 7.0

length 1: 56.5

length 2: 47.5

length 3: 26.5

stem diameter: 3.0

stem step diameter: 1.8

Materials

ball material: Carbide

base material: Stainless Steel

stem material: Stainless Steel
