TM2-2011-S-SN
TM2-2011-S-SN

TM2-2011-S-SN

$51.00
{% if Machines.userdata.machines[0].parts %} {% assign compatible = false %} {% for machine in Machines.userdata.machines %} {% if machine.parts contains title %} {% assign compatible = true %}
Compatible with
{{machine.make}} {{machine.model}} {{machine.probe_head}}
 {% endif %} {% endfor %} {% unless compatible %}
This product is not compatible with any of your saved machines.
{% endunless %} {% else %} {% endif %}
M2 stylus with 2.0 mm diameter silicon nitride ball and stainless steel stem and base. Stem diameter is 1.0 mm. Base diameter is 3.0 mm. Stylus length to ball center is 10.0 mm. Stylus weight is 0.26 gram. Compare to Renishaw A-5003-6120.

Dimensions

ball diameter: 2.0
base diameter: 3.0
length 1: 11.0
length 2: 6.5
stem diameter: 1.0

Materials

ball material: Silicon Nitride
base material: Stainless Steel
stem material: Stainless Steel
