TM2-0310-BC

Name: TM2-0310-BC
Brand: Q-Mark Manufacturing Inc.
Price: 209.0 USD
Availability: InStock

$209.00

{% if Machines.userdata.machines[0].parts %} {% assign compatible = false %} {% for machine in Machines.userdata.machines %} {% if machine.parts contains title %} {% assign compatible = true %}

Compatible with

{% endif %} {% endfor %} {% unless compatible %}

This product is not compatible with any of your saved machines.

{% endunless %} {% else %} {% endif %}

Quantity

M2 stylus with 0.3 mm diameter carbide cylinder. 3.0 mm diameter x 7.0 mm long stainless steel base. Stylus length to ball center is 10.0 mm. Stylus weight is 0.28 gram. Compare to Renishaw A-5003-1208.

Cylinder styli are used for edge probing, for example, the edges of stampings, or sheet metal. They are not suitable for high accuracy work because their form is not as precise as a sphere. Please contact Q-Mark for answers about using cylinder styli.

Dimensions

ball diameter: 0.3

base diameter: 3.0

length 1: 10.0

length 2: 3.0

Materials

ball material: Carbide

base material: Stainless Steel
