STR3-2050

$138.00
{% if Machines.userdata.machines[0].parts %} {% assign compatible = false %} {% for machine in Machines.userdata.machines %} {% if machine.parts contains title %} {% assign compatible = true %}
Compatible with
{{machine.make}} {{machine.model}} {{machine.probe_head}}
{% endif %} {% endfor %} {% unless compatible %}
This product is not compatible with any of your saved machines.
{% endunless %} {% else %} {% endif %}
M3 5-way star probe with center stylus.   Five 2.0 mm diameter ruby balls on 1.0 mm diameter stainless steel stems.  Distance between opposite ball centers is 50.0 mm.  Center stylus length is 28.0 mm to ball center.  Weight is 5.11 grams.  Compare to Renishaw A-5003-0077 and Mitutoyo K651166.

Dimensions

ball diameter: 2.0
length 1: 50.0
length 2: 28.0
stem diameter: 1.0

Materials

ball material: Ruby
base material: Stainless Steel
body material: Stainless Steel
stem material: Stainless Steel
