3-port TP20 stylus module rack with 700 mm wide rack support rail (RSR).  This bundle provides automated changing and covered storage for up to three TP20 stylus modules.  The rack uses a passive system, driven by the motion of the CMM and without additional motors or cables, to lock and unlock the probe head autojoint when changing components. TSR is part of a modular rack system which includes stylus storage racks (SSR), scanning module storage racks (MSR) and a range of different length rack support rails (RSR).  The image shows a 5-port autojoint rack (TSR-5, left) and 3-port TP20 stylus module rack (SSR-20, right).  The TSR-5 is not included in this bundle.
