M4 stylus for Faro Quantum arm CMM with 3.0 mm diameter zirconia ball, 2.5 mm diameter carbide stem, and 7.0 mm diameter stainless steel base with wrench flats. Stylus length to ball center is 12.0 mm. Compare to Metrology Works QT-PRS-5MM-ZIR.

QMFQ-50-Z

Name: QMFQ-50-Z
Brand: Q-Mark Manufacturing Inc
Price: 95.0 USD
Availability: InStock

$95.00

{% if Machines.userdata.machines[0].parts %} {% assign compatible = false %} {% for machine in Machines.userdata.machines %} {% if machine.parts contains title %} {% assign compatible = true %}

Compatible with

{% endif %} {% endfor %} {% unless compatible %}

This product is not compatible with any of your saved machines.

{% endunless %} {% else %} {% endif %}

Quantity

M4 stylus for Faro Quantum arm CMM with 3.0 mm diameter zirconia ball, 2.5 mm diameter carbide stem, and 7.0 mm diameter stainless steel base with wrench flats. Stylus length to ball center is 12.0 mm. Compare to Metrology Works QT-PRS-5MM-ZIR.

Dimensions

ball diameter: 5.0

base diameter: 7.0

length 1: 14.5

length 2: 8.5

stem diameter: 2.5

Materials

ball material: Zirconia

base material: Stainless Steel

stem material: Carbide
