M5 stylus with 3.5 mm diameter ruby ball, 2.5 mm diameter carbide stem, and 11.0 mm diameter x 10.0 mm long titanium base. Overall stylus length is 100.0 mm. Stylus weight is 9.25 grams. Compare to ITP TH M5 035 11 100/90.
M5 stylus with 3.5 mm diameter ruby ball, 2.5 mm diameter carbide stem, and 11.0 mm diameter x 10.0 mm long titanium base. Overall stylus length is 100.0 mm. Stylus weight is 9.25 grams. Compare to ITP TH M5 035 11 100/90.

ATG-35100-T

$130.00
{% if Machines.userdata.machines[0].parts %} {% assign compatible = false %} {% for machine in Machines.userdata.machines %} {% if machine.parts contains title %} {% assign compatible = true %}
Compatible with
{{machine.make}} {{machine.model}} {{machine.probe_head}}
 {% endif %} {% endfor %} {% unless compatible %}
This product is not compatible with any of your saved machines.
{% endunless %} {% else %} {% endif %}
M5 stylus with 3.5 mm diameter ruby ball, 2.5 mm diameter carbide stem, and 11.0 mm diameter x 10.0 mm long titanium base. Overall stylus length is 100.0 mm. Stylus weight is 9.25 grams. Compare to ITP TH M5 035 11 100/90.

Dimensions

ball diameter: 3.5
base diameter: 11.0
length 1: 100.0
length 2: 90.0
stem diameter: 2.5

Materials

ball material: Ruby
base material: Titanium
stem material: Carbide
