Q-Mark Probe Styli: Orders Placed by Noon PT Ship Out Same-Day* | Ultra-Fast Service | Always Guaranteed | Proudly USA Made

AQG-2045

Name: AQG-2045
Brand: Q-Mark Manufacturing Inc
Price: 80.0 USD
Availability: InStock

$80.00

{% if Machines.userdata.machines[0].parts %} {% assign compatible = false %} {% for machine in Machines.userdata.machines %} {% if machine.parts contains title %} {% assign compatible = true %}

Compatible with

{% endif %} {% endfor %} {% unless compatible %}

This product is not compatible with any of your saved machines.

{% endunless %} {% else %} {% endif %}

Quantity

M5 stylus with 2.0 mm diameter ruby ball, 1.0 mm diameter carbide stem, and 11.0 mm diameter by 20.0 mm long tapered stainless steel base. Overall stylus length is 45.0 mm. Stylus weight is 7.15 grams. Compare to Zeiss 626115-0203-045.

Dimensions

ball diameter: 2.0

base diameter: 11.0

length 1: 45.0

length 2: 35.0

length 3: 25.0

stem diameter: 1.0

Materials

ball material: Ruby

base material: Stainless Steel

stem material: Carbide
