TM3-S30R-C
TM3-S30R-C

TM3-S30R-C

$65.00
{% if Machines.userdata.machines[0].parts %} {% assign compatible = false %} {% for machine in Machines.userdata.machines %} {% if machine.parts contains title %} {% assign compatible = true %}
Compatible with
{{machine.make}} {{machine.model}} {{machine.probe_head}}
 {% endif %} {% endfor %} {% unless compatible %}
This product is not compatible with any of your saved machines.
{% endunless %} {% else %} {% endif %}
M3 carbide pointer stylus, 36.1 degree, for ROMER arm CMM.  1.0 mm diameter wrench hole.  Overall stylus length is 7.54 mm.  Stylus weight is 0.53 gram.  Compare to Hexagon 74133.

Dimensions

base diameter: 4.0
length 1: 10.0
length 2: 5.0
stem diameter: 1.5

Materials

base material: Stainless Steel
stem material: Carbide
