TM2-4022-B

$128.00
{% if Machines.userdata.machines[0].parts %} {% assign compatible = false %} {% for machine in Machines.userdata.machines %} {% if machine.parts contains title %} {% assign compatible = true %}
Compatible with
{{machine.make}} {{machine.model}} {{machine.probe_head}}
{% endif %} {% endfor %} {% unless compatible %}
This product is not compatible with any of your saved machines.
{% endunless %} {% else %} {% endif %}
M2 stylus with 4.0 mm diameter ruby cylinder and stainless steel base. Overall stylus length is 20.0 mm. Stylus weight is 0.93 gram. Compare to Renishaw A-5003-0073. Cylinder styli are used for edge probing on stampings or sheet metal parts. They are not suitable for high accuracy work because the form of a cylinder is not as precise as a sphere. Please contact us with any questions about calibrating or using cylinder styli.

Dimensions

ball diameter: 4.0
base diameter: 3.0
length 1: 22.0
length 2: 10.0
stem diameter: 2.0

Materials

ball material: Ruby
base material: Stainless Steel
stem material: Stainless Steel
